Pioneer gm a3702 | Pioneer amplifier review.
- Max power output: 170 W x 2 (4§Ù) / 500 W x 1 (4§Ù Bridged)
- Minimal power output: 60 W x 2 (4§Ù) or 95 W x 2 (2§Ù) or 190 W x 1 (4§Ù Bridged)
- Frequency Response: 10 Hz to 70 KHz
- Impedence: 4§Ù ( 2§Ù to 8§Ù allowable )
- Total Harmonic Distortion (THD): <0.05% (1 kHz, 4§Ù)
- S/N Ratio: > 95 dB
- LPF: 80Hz
- RCA Terminals: 2ch
- Speaker Terminals: Screw-type
- Input Level control: 300mV - 6.5 V
- Highlight feature: Automatic Signal Sensing & Turn-On
Approximate Dimensions:
- Height: 2.36"
- Width: 9.7"
- Depth: 7.1"
